Cabochon outline maker · Free · No account
A cabochon template drawn at the size you type, with a square to check the print.
Type a width and height in millimetres or inches and this maker fills a page with oval or circle outlines at that size, each with centre marks and its size, plus a square to check the print. A second page gives a stage and scratch check card. The PDF is free.
- A4 and US Letter
- Prints at actual size
- Goes with The Lapidary Process Book
- Type the sizeChoose oval or circle, then type the width and height from 3 to 120 mm, or the same in inches.
- Name your stagesOptionally list up to eight of your own stage names for the check card, such as your grits or laps.
- Print and measurePrint at 100%, measure the 50 mm square with a ruler, then use the outline if the square is right.
Make your card
The page beside the form changes as you type. The PDF is made in your browser and is sized for A4 or US Letter.
Enable JavaScript in your browser to use this tool.
File details
- What it works out
- It draws an oval or circle at the width and height you type, converting inches at 25.4 mm each.
- Using the result
- Enter stages and settings suited to the stone and equipment you are using.
- Calculation
- The sizes are the ones you type; the outline is a standard ellipse drawn as vector curves.
- A guide
- The printed outline is a guide for marking a slab.
Questions
Is the outline the exact size I typed?
In the PDF it is drawn to the size typed, measured to the centre of a 0.25 mm line. On paper it matches only when the printer prints at 100%.
How do I print it at actual size?
In the print window choose 100% or Actual size, and turn off Fit to page. Then measure the square: it must be 50 mm each way.
Can I type the size in inches?
Yes. Choose inches and type, for example, 1.5 by 1. The card prints both units, such as 38.1 mm (1.50 in).
What is the stage and scratch check card?
Page two lists your stages with a tick box for ‘scratches from the last stage gone’, a date line and a notes line.
Related Due Form edition
The Lapidary Process Book
A workshop record for following rough stone through planning, cutting, grinding, sanding and polish.
Request a tool or send feedback
Request a tool or report a problem
Tell us what you would like to add, change or fix in the Cabochon outline maker.
